General | Specifications | |
---|---|---|
Centre Height | MM | 140/165 |
Max. Grinding Lenght | MM | 300/450/600 |
CNC / PLC System | SIEMENS/FUJI/DELTA | |
Rapid Feed (X & Z axes) | MM/MIN | 7000 |
Min. Incremental Feed (X & Z axes) | MM | 0.001 |
Grinding Wheel Head | ||
Grinding Wheel Diameter | MM | 355/405 |
Grinding Wheel Width | MM | 25/38/50 |
Motor Power | HP | 3/5 |
Work Head | ||
Speed Range | RPM | Variable |
Spindle Nose Taper | MT | 3/4 |
Tailstock | ||
Tailstock Centre | MT | 3/4 |
